Venue Specs

Gild Hall is a 160 year old barn that was turned into a concert venue and theater 100 years ago by the founders of the Utopian community of Arden. We can seat 250 people in the hall or we can do a 300 person standing event. The stage is 3 foot raised from a hardwood dance floor and the walls are all wood with a high acoustic ceiling. The stage is 23 by 23 with 15 feet usable height. We provide full lighting with smoke and color effects as well as high performance sound system and a sound engineer.

Sound System: Monitors from FOH.

Sound Spec:

2x EV QRX212 Biamplified loudspeaker
1x Clair Bros. ML-18 Subwoofer
4x Dynacoustics M-122 12”+2” monitor loudspeaker
1x Main amplification rack w/ dbx Driverack 480 DSP
1x Monitor amplification rack (4 Mixes)
1x Processing Rack

  • TC M One effects processor
  • dbx 166XL dual comp / gate
  • dbx 1066 dual comp / gate
  • 2x dbx 160X comp
  • Drawmer DS201 dual gate
  • dbx 1231 “Mains” graphic EQ
  • dbx 231 EQ (spare / fills / etc.)

1x Monitor EQ rack

  • 1x dbx 166XL dual comp / gate
  • 2x dbx 1231 graphic EQ

1x Soundcraft LX7II 24CH mixer, 4 pre-fade monitor mixes from FOH, 2 post-fade sends to effects.
1x Microphone package consisting of:

  • Audix D6
  • Shure Beta 52
  • Shure SM91
  • 6x Shure SM57
  • 6x Shure SM58
  • 4x Shure Beta 58
  • 1x Sennheiser E609
  • 6x Sennheiser E604
  • 2x AKG C535
  • 2x AKG C414B/XLS
  • 2x Radial JDI
  • 1x Radial ProDI
  • 1x Countryman 85
  • 3x LDB-101 Active DI box
  • K&M / Atlas mic stands

1x 16ch Main snake
1x 8ch Main snake
1x 6CH subsnake
1x 4CH subsnake

System is stereo with bi-amped mains + sub. Capable of 105dba at FOH with headroom.
